Dengan konstruksi rangka baja dan material jok premium, Chester Bristol Pro memberikan stabilitas tinggi tanpa mengorbankan kenyamanan. Seri S1000 dan S1500 hadir dengan tingkat penyesuaian berbeda, memungkinkan pengguna menyesuaikan posisi duduk sesuai kebutuhan ergonomis. Sangat ideal untuk pekerja yang duduk berjam-jam di depan komputer.
Chester Bristol Pro (S1000 & S1500)
Chester Bristol Pro mengutamakan dukungan postur alami untuk mencegah nyeri punggung dan leher. Fitur reclining, armrest adjustable, dan sistem hidrolic smooth membuat pengalaman duduk lebih nyaman dan fleksibel. Tersedia dalam beberapa pilihan warna netral yang elegan untuk melengkapi suasana ruang kerja modern.
Features
Overview
| Model | Bristol S 1000 | Bristol S 1500 |
|---|---|---|
| Centre Height | 205 mm | 205 mm |
| Swing over Bed | 410 mm | 410 mm |
| Distance between Centres | 1000 mm | 1500 mm |
| Swing over Cross Slide | 255 mm | 255 mm |
| Swing in Gap | 580 mm | 580 mm |
| Gap Length in front of Face Plate | 190 mm | 190 mm |
| Cross Slide Travel | 210 mm | 210 mm |
| Top Slide Travel | 140 mm | 140 mm |
| Bed Width | 250 mm | 250 mm |
| Max. Workpiece Weight | 150 kg | 150 kg |
| Spindle Nose | D1-6 | D1-6 |
| Spindle Bore | 52 mm | 52 mm |
| Spindle Taper | MT6 | MT6 |
| No. of Spindle Speeds | 16 | 16 |
| Spindle Speed Range | 45–1800 rpm | 45–1800 rpm |
| Tool Section | 20 × 20 mm | 20 × 20 mm |
| Tailstock Quill Diameter | 50 mm | 50 mm |
| Tailstock Quill Travel | 120 mm | 120 mm |
| Tailstock Internal Taper | MT4 | MT4 |
| Longitudinal Feeds | 0.05–1.7 mm/rev | 0.05–1.7 mm/rev |
| Cross Feeds | 0.025–0.85 mm | 0.025–0.85 mm |
| Metric Threads | 0.2–14 mm (39 steps) | 0.2–14 mm (39 steps) |
| Imperial Threads | 2–72 TPI (45 steps) | 2–72 TPI (45 steps) |
| Module Threads | 0.3–3.5 MP (18 steps) | 0.3–3.5 MP (18 steps) |
| Diametrical Threads | 8–44 DP (21 steps) | 8–44 DP (21 steps) |
| Leadscrew Pitch | 6 mm | 6 mm |
| Main Motor | 2.2 kW (3 hp) | 3.3 kW (4.5 hp) |
| Coolant Pump Motor | 0.1 kW (0.13 hp) | 0.1 kW (0.13 hp) |
| Dimensions (L×W×H) | 1940 × 850 × 1320 mm | 2440 × 850 × 1320 mm |
| Net Weight | 1160 kg | 1340 kg |
