SWA 300F/450F menawarkan beam laser berkualitas tinggi dan stabilitas proses yang meningkat — memungkinkan jalur las melingkar, bidang miring, pengisian material, serta tumpang‑tindih seam dengan bantuan software intuitif. Minim perawatan karena tanpa bagian konsumabel.

Chester Chieftain Series-1 Manual Lathe

Dengan sumbu X, Y, Z yang memungkinkan gerakan presisi hingga stroke besar, sistem ini cocok untuk mold ukuran besar. Konsep frekuensi pulsa hingga 50Hz dan durasi 0,1‑10 ms memberi fleksibilitas tinggi untuk aplikasi industri cetakan mold & die.

Features

Sumber laser fiber generasi baru

memproduksi beam laser 1070 nm dengan daya rata‑rata hingga 300W/450W dan puncak hingga 3kW/4.5kW.

Maintenance‑free / tanpa konsumabel

desain yang menghilangkan kebutuhan bagian habis pakai, mengurangi downtime dan biaya servis.

Software operasi lanjutan (“Tracked Routes”)

mendukung jalur las melingkar, bidang miring, pengisian dan fungsi overlap untuk hasil sambungan las yang sangat teratur.

Fleksibilitas mekanis yang tinggi

gerakan sumbu X/Y/Z dengan stroke besar (X 300mm, Y 150mm, Z 500mm) dan head laser yang dapat diorientasi untuk area sulit.

Kualitas hasil las dan material sangat luas

dapat lakukan las pada baja, paduan tembaga, aluminium; tak perlu pra‑panaskan, menghindari distorsi atau dekarburisasi.

Overview

Category	Specification Item	Series-16	Series-20	Series-26	Series-32
Centre Height	Height from bed to centre line	200 mm	250 mm	330 mm	400 mm
Swing Over Bed	Max diameter over bed	400 mm	500 mm	660 mm	800 mm
Distance Between Centres	Length usable between headstock & tailstock	1000 / 1500 / 2000 / 3000 mm	same	same	2000 / 3000 mm
Swing Over Cross Slide	Diameter over cross slide	200 mm	300 mm	420 mm	560 mm
Swing in Gap	Diameter that can swing in the gap	630 mm	710 mm	870 mm	1000 mm
Gap Length in Front of Face Plate	Depth of gap	240 mm each series
Cross Slide Travel	Travel of cross slide	320 mm	320 mm	310 mm	320 mm
Top Slide Travel	Travel of compound / top slide	145 mm (all)
Bed Width	Width of the bed structure	390 mm (all)
Spindle Nose	Standard nose type	D1-6	D1-8	D1-8	ISO702 / Cam-lock etc.
Spindle Bore	Inner diameter bore through spindle	52 mm	105 mm	105 mm	105 mm
Spindle Speed Ranges / Steps	Number of spindle speed steps & range	24 steps (16 series: 9-1600 rpm)	12 steps	12 steps	12 steps
Tailstock Quill Diameter	Diameter of tailstock quill	75 mm	75 mm	75 mm	90 mm
Tailstock Quill Travel	How far quill extends	150 mm (all)
Tailstock Taper	Internal taper in tailstock	Morse 5 (all)
Longitudinal Feeds	Longitudinal feed range & of options	0.028-6.43 mm/rev (93 kinds)	0.63-2.52 mm/rev (65 kinds)	0.63-2.52 mm/rev (65 kinds)	0.063-2.52 mm/rev (65 kinds)
Cross Feeds	Cross feed range & of options	0.012-2.73 mm/rev (93 kinds)	0.027-1.07 mm/rev (65 kinds)	0.027-1.07 mm/rev (65 kinds)	0.027-1.07 mm/rev (65 kinds)
Metric Threads	Metric thread pitches	0.5-224 mm (48 kinds)	1-14 mm (22 kinds)	1-14 mm (22)	1-14 mm (22)
Imperial Threads	Imperial thread pitches	72-1/8 TPI (46 kinds)	28-2 TPI (25 kinds)	28-2 TPI (25)	28-2 TPI (25)
Module Threads	Module pitches supported	0.5-112 mm (42 kinds)	0.5-7 mm (18 kinds)	0.5-7 mm	0.5-7 mm
Main Motor	Motor power	7.5 kW (10.05 HP) for all models
Coolant Pump Motor	Pump motor size	0.12 kW (0.16 HP) (all)
Net Weight	Weight of the machine	2050-2850 kg	2100-2900 kg	2200-3000 kg	3000-3200 kg
