Mesin Bandsaw Automatic Mitre HBE520-926GA memberikan kemudahan produksi melalui sistem servo feed, kontrol tekanan potong otomatis, dan double clamping vice yang stabil. Cocok untuk garapan struktur baja besar serta integrasi dengan material handling otomatis.
Bandsaw Machine Automatic Mitre HBE520-926GA BEHRINGER
HBE520-926GA BEHRINGER dirancang untuk high throughput di lini pemotongan otomatis. Pemandu band dari besi cor, sudut mitre yang diatur secara elektronik, serta chip brush elektrik meningkatkan stabilitas, umur pisau, dan kualitas hasil potong.
Features
Overview
| Kategori | Spesifikasi |
|---|---|
| Model | BEHRINGER HBE520-926GA Automatic Mitre Bandsaw |
| Jenis | Automatic Mitre Bandsaw Machine |
| Cutting Capacity 90° Round | 520 mm |
| Cutting Capacity 90° Flat | 820 × 520 mm |
| Feeding Length (Single Stroke) | 3,000 mm |
| Drive Power | 5.5 kW |
| Blade Speed | 17–120 m/min |
| Saw Blade Dimensions | 8,500 × 54 × 1.6 mm |
| Minimum Cut Length | 55 mm |
| Rest Piece Length (Automatic) | 150 mm |
| Total Power | 11 kW |
| Saw Feed | Servo-feed via ball screw |
| Material Feed | Servo motor via gear rack |
| Material Clamping | Hydraulic |
| Saw Blade Cleaning | Electrically driven chip brush |
| Dimensions L × W × H | 7,000 × 4,700 × 3,240 mm |
| Weight | 7,000 kg |
| Material Support Height | 800 mm |
